Max.Power Consumption 1W,and TO Packaging Features
Small 10G Form Factor Factor for Greatest Density per Chassis
Support 4x10G Fan out and Easy Migration to 40G Platforms
FS BOX - Support Real-time Configuration
Hot Pluggable SFP+ MSA and RoHS Compliant
Cisco Compatible | SFP-10D-5R | Vendor Name | Imorecable |
Form Factor | SPF+ | Max Data Rate | 10.3125Gbps |
Wavelength | 850nm | Max Cable Distance | 300m@OM3/400M@OM4 |
Connector | Duplex LC | Media | MMF |
Transmitter Type | VCSEL | Receiver Type | PIN |
TX Power | -7.3~-1dB | Receiver Sensitivity | <-11.1dBm |
Power Budget | 3.8dB | Receiver Overload | -1dBm |
Typical Power Consumption | ≤1W | Extincion Ratio | >3dB |
DDM/DOM | Supported | Commerial Temperature Range | 0 to 70℃(32 to 158℉) |
Core Size | 50/123um | Modulation | NRZ |
Protocols | IEEE 802.3ae,SFF-8472,SFF-8431,SFF-8432,SFP+ MSA Compliant,CPRI,eCPRI | Warranty | 5 Years |
