MTP-8 to LC x4 Shuttered Cassette

MTP-8 to 4x LC Duplex Fiber Optic Cassette, OM4 50/125um,Universal,8 Fibers,Plug-N-Play

FHD® High Density series MTP® fiber cassettes are pre terminated,pre tested,and come with one rear 8 fiber MTP® port connection and 4 duplex LC ports.The MTP®-8 cassteet is ideal for deployments including 40G to 10G,100G 25G and 400G to 100G.Universal polarity to be used at both ends of a Method B trunk reduces the complexity of a fiber network,ensuring consistent polarity,and streamlining entwork maintenance.

This Base-8 MTP® fiber cassette is designed to upgrade existing LC links to SR4 parallel optics without wasting any of the fibers inside the cable.

Models

Online inquiry

Share:

Leave a message

X

Name *

Email *

Tel

Website Link

Content

Features

Internal Shutters Speed Deployment and Ensure Safer Link

Universal Polarity Requires Method B Trunks on Each Ewd

Rear-loading Capability Decreases Time to lnstall Cassettes

12 Cassettes Fit into 1U FHX Enclosure,Up to 96 Fibers

0.35dB Low Insertion Loss Alloes for Longer Link Distances

Product attributes

Fiber Count8 FibersFiber ModeOS2 9/125
Front Connector TypeShuttered LC Guplex(Blue)Number of LC Port4 Ports
Rear Connector TypeUS Come MTP APC(Pinned)Number  of MTP Port1 Port
MTP Adapter TypeKey Up to Key DownHousing TypeCassette
Material of SleeveZirconia CeramicMaterial of Cassette BodyPC
PolarityUniversalDimensions(HxWxD)0.46''*2.40''*5.13''(11.6*61*130.3mm)
Insertion LossMTP≤0.35dB,LC≤0.2dBReturn LossMTP≥60dB,LC≥50dB
StandardRoHS CompliantApplicationMatching for FHX Base-8 Enclosure
